Product description & features
- Integrated sealing and shrinking in one step.
- Transparent hood makes the sealing and shrinking visible.
- Glass fiber cutler’s isolator and nickel alloy cutter in order to result in perfect sealing line, to avoid the film sticking the cutter. It has a special roller with a pin to make small holes on the film.
- Does not become over hot after a long period of operation.
- PPS thermostable cutter clip to bear heavy tension after long periods of operation
- The height of the package supporting mesh inside the chamber can be adjusted for different sizes of products.
- Assembled castors with brake on the bottom of supporting base, to move and fix the machine freely.
- GPK-5540A is equipped with a stainless steel conveying mesh with adjustable height transporting the products from the sealing and shrinking automatically, this increase the packing capacity by double.
Scope of Application
- This machine is widely used for outside shrink packing by film, such as foodstuff, beverage, pharmacy, video disc, hardware, cosmetics, book, toy and electronic products etc;
- Suitable for shrink wrapping a combined product for sales promotion in supermarket, such as foodstuff, beverage, cosmetics, presswork and toy etc;
- Suitable to put and use it in a small room where space is limited such as supermarket, monopolization shop, office and some experimental room etc;
Technical Specification
Model | GPK-5540A |
Machine dimensions LxWxH (mm) | 1985x690x1065 |
Machine packing size LxWxH (mm) | 450x300x200 |
Machine sealing size LxWxH (mm) | 550×400 |
Packing speed (pcs/h) | 800-1000 |
Netweight (kg) | 140 |
Power (kw) | 4.2 |
Power supply | 1f110V/220V 50/60Hz |
