Description
Cooking and processing pots
- 300L heating three layers high speed mixing homogenizer tank
- Working volume: 300L design
- volume: 350L
- Inner layer: SUS316 3mm;
- Middle layer: SUS304 3mm
- Outer layer: SUS 304 2mm
- Blending power: 1.5 kW
- Blending rotation speed: 0-63 r/min
- Top dispenser: 2.2kw
- Dispenser speed:0-1400rpm
- Inverter of blending: Taida
- Homogenizing power: 4 kw
- Homogenizing rotation speed: 0-2880 r/min
- Motor: Beide, Siemens
- Electric part: Delixi
- Voltage: AC 380 three phase 50Hz
Chilling unit
Air cooled water chiller Specifications:
- Power supply: 400 V /50 Hz 3Phase
- Compressor: Original DANFOSS hermetic scroll compressor
- Built-in SS water tank and water pump
- Original Schneider/CHINT electrical components
- R407c refrigerant
- 7C-35C chiller water temperature controlling range
Tabular pasteurizer
Screw Pump
Piston Filling Mchine: Including direct feed system
Machine parameters
- Voltage: 220V/60Hz, 110V/50Hz
- Air pressure: 0.4-0.6MPa
- Filling speed: ≤3000pcs/Hour
- Hopper Capacity: 30L
- Size: 900×380×310mm
- Tank/hopper size: 400×400×450mm
- Filling accuracy: ≤±1%
- Filling Range: 50-500ml
Bottle capping machine
Labeling machine
Coding and conveyor
CONVEYOR: 90mm wide, 2.5 meter long 304SS, VSD
Elfin II (single head)
Controller (7″ touch screen)
Elfin II print head x 1
Deflector component (singlex1)
Bracket + Power Adaptor
cable (120cmx1)
U disk + Grounding Cable
Accessories:
Synchronizer, sensor, alarm kit, anti-shock deflector mechanism.
